Diamond Antenna C101-3/8C Antenna mount cable assembly, 3/8C, 6ft
Diamond Antennas C101-3/8C Cable AssemblyUse of PTFE 1/8" diameter coax, which is very flexible, and small mini-UHF connectors allow for easy installation through tight vehicle body panels.Special Features:Replacement cable for K400-3/8C 6.5' RG316 PTFE 1/8" diameter coaxMini-UHF Connectors
Diamond Antenna K9000LRM Luggage rack mount, motorized
Diamond Antennas K9000LRM Motorized Luggage Rack MountRaise and lower your antenna with a touch of the button with the K9000 motorized mount for luggage racks.Special Features:Accepts "Ground Independent" antennas up to 45" in length0-90° range; operates from 12VDC with fused cigarette plugIncludes 20' cable to switchCompatible with Diamond C-series base/cable assembliesAlso available for trunk and hatchback installationsRemarks: Use C-series cable assemblies. Recommended Diamond antennas include NR73BNMO, NR770HNMO, NR770HBNMO, NR770HA, NR770HB, SG7500A & SG7500NMO.
Diamond Antenna K400CNMO Lip mount, 2-axis adjustable Antenna Vehichle Mount with NMO Connector
Diamond K400 Trunk / Lip / Hatchback Antenna MountSpecifications:Strongest, most universal, style of mobile mount2-Axis adjustment provides placement flexibilityNo Holes / Drilling RequiredRubber pad protects mounting surfaceRecommended for larger antennas (will suport ATAS-120)NMO to PL-259 with 6.5' RG-316 Teflon coax cable
Diamond Antenna MX72D Duplexer: 1.6-30+140-150/400-460MHz
Diamond Antennas MX72D HF-2M / 70cm Duplexer Product Specifications Band Pass: Low: 1.6 - 150MHz; High: 400 - 460MHz Ins. Loss: Low: 0.1dB; High: 0.2dB Max Power: Less than 30MHz: 1000W PEP; 140-150MHz : 400W PEP; 400-460MHz: 250W PEP Isolation: 60dB Connectors: Output: SO-239; Low Input: PL-259; High Input: PL-259
Diamond Antenna MX62M Duplexer: 1.5-56/76-470MHz, HF+6/VHF+UHF
Diamond Antennas MX62M HF-6M / 2M-70cm Duplexer Jumpered Connectors on Inputs -- Ideal for IC-706MK2G Product Specifications Port: LPF/HPFFrequency (MHz):1.6-56/76-470CW W: 200/200PEP W: 600/600Loss dB: .2/.3Isol dB: 50/50Mix Connector: SO-239Port connector: PL-259/12" 5D cable
Diamond Antenna K400S Lip mount, 2-axis adjustable Antenna Vehichle Mount with SO-239 Connector
Diamond K400 Trunk / Lip / Hatchback Antenna MountSpecifications:Strongest, most universal, style of mobile mount2-Axis adjustment provides placement flexibilityNo Holes / Drilling RequiredRubber pad protects mounting surfaceRecommended for larger antennas (will suport ATAS-120)NMO to SMA with 13.5' RG-316 Teflon coax cable
Diamond Antenna K515SNMO Luggage rack Mount, NMO, 13ft coax +SMA
Diamond Antennas K515SNMO Luggage Rack Mount Universal luggage carrier mount. Ideal for new SUV designs. Special Features: Black finish 1.5 inch mounting width Two-axis adjustable 13.5 ' RG316 PTFE coax, with SMA (M), And PL-259 Adapter NMO base Includes RSA3474 adapter for mobile radios Includes: Allen wrenches Mounting hardware Adhesive cable holders SMA female to PL-259 adapter (RSA-3474) Weather cap
Diamond Antenna K9000TM Lip mount, motoroized
Diamond Antennas K9000LRMO Motorized Luggage Rack Mount Raise and lower your antenna with a touch of the button with the K9000 motorized mount for luggage racks. Special Features: Accepts "Ground Independent" antennas up to 45" in length 0-90° range; operates from 12VDC with fused cigarette plug Includes 20' cable to switch Compatible with Diamond C-series base/cable assemblies Also available for luggage rack and oversize luggage rack installations Remarks: Use C-series cable assemblies. Recommended Diamond antennas include NR73BNMO, NR770HNMO, NR770HBNMO, NR770HA, NR770HB, SG7500A & SG7500NMO.
Diamond Antenna K515S Luggage rack Mount, UHF, 13ft coax +SMA
Diamond Antennas K515S Luggage Rack MountUniversal luggage carrier mount. Ideal for new SUV designs.Special Features:Black finish 1.5 inch mounting widthTwo-axis adjustable 13.5' RG316 PTFE coax, with SMA (M), And PL-259 AdapterSO-239 base Includes RSA3474 adapter for mobile radiosIncludes:Allen wrenchesMounting hardwareAdhesive cable holdersSMA female to PL-259 adapter (RSA-3474)Weather cap
Diamond Antenna C213SNMO Antenna Mount Cable asembly, NMO SMA 13ft
Diamond Antennas C213SMA Cable Assembly Special Features: Fits all Diamond® Antenna K-Series mounts (except K600M) 13.5 ' RG316 PTFE 1/8" diameter coax Low-loss PL259 adapter included NMO base
Diamond Antenna A144S10 2m (144-148MHz) 10 El. Base Station Yagi Beam Antenna
Special Features:Super High GainEasy AssemblyGreat for base or portable use.Quality ConstructionFactory adjusted no tuning required. Specifications:Power Rating: 50 wattsFrequency: 144-148 MHzBand: 2m Yagi (10 element)Connector: UHFGain: 11.6 dBiWeight: 2.4 lbs.Dimensions: 7" x 3.6" x 2.9'Max Wind Resistance: 80 MPHRemarks: Center element insulated from ground.
Diamond Antenna RH519 HT Antenna 2m/70cm, BNC, 8in
Diamond Antennas RH519 HT/Scanner Antenna Flexible, slim design with BNC. Also available in SMA.Product Specifications: Coverage: 2M, 70cm Gain* (relative): 3dB Max Power: 10 watts Length: 7.75" Connector: BNC Remarks: *Rated against typical stock HT antennas.
Diamond Antenna SRH805 HT antenna, 2m/70cm/23cm, SMA, 1.75in
Diamond Antennas SRH805 HT AntennaHigh quality, high gain HT antenna. Compact design with SMA. Increase the performance on your handheld or wideband scanner with a Diamond® SRH Series antenna.Specifications:Bands: 2m/70cm/23cmGain* (relative): -2dBWatts: 6Height: 1.75"Connector: SMARemarks: *Rated against typical stock HT antennas.
Diamond Antenna BNCJ-SMAP Low Profile Black Adapter BNC-F/SMA-M
Adapter for SMA equipped handhelds to use BNC antennas. Low profile design reduces amount of torque applied to the handheld antenna connector. Sleek 1 piece design, black in color with gold contacts. Rubber ring around edge for better grip. Simply the best SMA to BNC adapter for a handheld application.
Diamond Antenna CP610 Vertical base antenna, 10m/6m, 22ft
Diamond Antennas CP610 6m Antenna Specifications: Frequency: 6m/10m Power: 500 watts SSB, 200 watts FM Gain: 5.5 dB/ 3.4 dB Impedance (output): 50 ohms VSWR: 1.8: 1 (Nominal) Element Phasing: 2-5/8 wave/1-5/8 wave Max Wind Rating: 80 mph (no ice) Mast Diameter Acceptance: 1.2" - 2.4" Overall Length: 22' ( 6.7 m) Connector: SO239 female UHF
Diamond Antenna K702M Magnetic Antenna Mount, UHF, 16ft coax
Diamond Antennas K702M Magnet MountDeluxe low-profile magnet mount with high holding power. Aerodynamic styling.Special Features:6 3/8" diameter, 3/4" height13' RG-58A/U cable and PL-259Includes thin mylar sheet to enhance grip and protection of paintFor VHF/UHF antennas up to 50"
Diamond Antenna MR73SMA Magmount Antenna 2m/70cm, 13ft coax SMA
Diamond Antennas MR73SMA Dualband Mobile Antenna - Magnet Mount/Antenna CombinationSpecifications: Bands: 2m/70cmGain dBi: 2.15/3.4dbiMax Power Rating: 10wHeight: 20"Mount: 1.25" MagnetImpedance: 50 ohmsCoax: 9'10" RG174/U w/ SMA Connector
Diamond Antenna DL-30A Dummy load 100W 0-500MHz PL-259, compact
Diamond Antennas DL30A Compact Dummy LoadSpecifications:Frequency: DC-500 MHzRated Power: 15 watts continuous, 100 watts peakConnector: PL-259Impedance: 50ohmsVSWR: 1.15Dimensions: 30mm Diameter x 75mm Length
Diamond Antenna SP1000PW Lightning Surge Protector, UHF (male) - UHF (female)
Specifications:Frequency Range: DC – 1,000 MHzSWR: less than 1.2Insertion Loss: less than 0.3 dBMax Power Rating: 400w PEPConnector: UHF male - UHF femaleImpulse Wave Discharge Voltage: 800vImpulse Wave Discharge Capacity: 6000AImpulse Wave Retention Discharge Capacity: DC350v ± 20%Insulating Resistance DC100v: Over 10,000M ohmsWeight: 130gDimensions: 78Wx55Hx26D mmImpedance: 50 ohms
Diamond Antenna HF17CL 17m Monoband Mobile Antenna with Fold-Over Hinge and UHF (SO-239) Connector
17m Monoband Mobile Antenna Specifications: Bands: 17m Watts: 200 SSB, 70 FM Height: 86.6" Element Phasing: 1/4 Connecotr: UHF Impedance: 50Ω
Diamond Antenna AZ504SP Dualband (2m / 70cm) Mobile Antenna with Spring and UHF Connector, 43in Tall
Diamond AZ504SP Dualband w/ Sprint Mobile Antenna Specifications: Bands: 144/440MHz Gain dBi: 2.15 dBi (440MHz) Max Power Rating: 50W FM (Total) Height: 15.5" Weight: 80g Mount: UHF Element Phasing: 144MHz -1/4l, 440MHz - 1/2 l VSWR: Less than 1.5 Impedance: 50 ohms
