4x1 (4K@60Hz/18G/444) HDMI Switcher with L/R / Optical Audio & De-Embedded Audio Output
Features:
- HDMI Switching: 4 HDMI sources to 1 HDMI output/display
- Ultra HD/4K Support:
4096x2160 or 3840x2160 24/25/30/60hz at 4:4: 4 (signals up to 18Gbps bandwidth) - HDCP Licensing: Fully licensed and compatible with HDCP 2.2
- HDR10 (High Dynamic Range): More life-like images through a greater range of luminance levels
- Resolution Support: Supports all SD, HD, and VESA (VGA, SVGA, XGA, WXGA, SXGA, UXGA) up to 4096x2160p.
- Deep Color Support:
Up to UHD/4K 30Hz 4:4:
4/12 bits or 60Hz 4:4: 4/8 bit - Audio De-embedding: Audio of the selected HDMI input is output at the digital Optical and analog 3.5 mm stereo connectors.
- Auto-Sensing: Automatic selection of newly detected source and switching from newly disconnected source via hot plug detection voltage when enabled
- Full Buffer System™: Manages TMDS re-clocking / signal re-generation, HDCP authentication to source & display, and EDID Control handshake
- EDID Management: Internal library with 15 internal EDID handshakes including 4K with HDR in addition to native EDID data copied from the output/display
- Lossless Compressed Digital Audio: Dolby® True
HD, Dolby® Digital Plus, DTS-HD Master Audio™, and Dolby® Atmos - CEC Pass-thru: From connected display to selected HDMI source
- Control: Front panel buttons/LEDs, Optical IR
- Control System Support: Compass Control® Pro ready. Fully controllable by all IR supported control systems
