SUPERMICRO SYS-5018A-MLTN4 1U Rackmount Server Barebone (Black)
CTNR1050791 0672042154012 CTNR1050791Supermicro
2025-12-18
/itm/supermicro-sys-5018a-mltn4-1u-rackmount-server-barebone-black-1050791
USD
512.15
$ 512.15 $ 527.99 3% Off
Item Added to Cart
customer
*Product availability is subject to suppliers inventory
SHIPPING ALL OVER UNITED STATES
100% MONEY BACK GUARANTEE
EASY 30 DAYSRETURNS & REFUNDS
24/7 CUSTOMER SUPPORT
TRUSTED AND SAFE WEBSITE
100% SECURE CHECKOUT
| Brand | SUPERMICRO |
|---|---|
| Model | SYS-5018A-MLTN4 |
| CPU Type | Intel Atom C2550 2.4GHz 4C/4T TDP 14W |
| CPU Socket | FCBGA 1283 |
| Installed CPU | 1 |
| Max Processors | 1 |
| Memory Slots | 4 x 240Pin |
| Installed Memory Size | No Memory Installed |
| Max Memory Supported | 64GB |
| Memory Type Supported | DDR3 1600/1333 |
| ECC Supported | Yes |
| Installed HDD | No Storage Installed |
| Serial ATA | 2 x SATA 600 + 4 x SATA 300 |
| GPU/VPU | BMC integrated Aspeed AST2400 |
| First LAN | C2000 SoC I354 Quad GbE Controller |
| Max. LAN Speed | 10/100/1000Mbps |
| 3.5" Bays | 2x 3.5" or 4x 2.5" internal SATA2 hard drive bays (optional) |
| COM | 2x Fast UART 16550 Serial Port (1 rear, 1 via header) |
| VGA | 1 |
| Rear USB | 7x USB 2.0 ports (4 rear, 1 Type A, 2 via header) |
| RJ45 | 4x RJ45 Gigabit Ethernet LAN ports 1x RJ45 Dedicated IPMI LAN port |
| Max. Power | 200W Low Noise AC-DC power supply with PFC |
| Features | 1x SATA DOM (Disk on Module) power connector TPM 1.2 header Front Panel Buttons Power On/Off button System Reset button LEDs Power LED Hard drive activity LED 2x Network activity LEDs System Overheat LED IPMI Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support Aspeed AST 2400 BMC |
| Form Factor | 1U Rackmount |
| Dimensions | 16.8" x 14" x 1.7" (D x W x H) |
| Weight | Net: 8lbs Gross: 31lbs |
Motherboard
Super A1SAM-2550F
Processor/Cache
CPU
Intel Atom Processor C2550
CPU TDP 14W (4-Core)
FCBGA 1283
System-on-Chip
System Memory
Memory Capacity
4x 240-pin DDR3 SO-DIMM sockets
Supports up to 64GB DDR3 ECC memory
Memory Type
1600/1333MHz ECC or non-ECC UDIMM SDRAM, 240-pin gold-plated DIMMs, x8 width only
DIMM Sizes
16GB, 8GB, 4GB, 2GB
Memory Voltage
1.5 V, 1.35 V
On-Board Devices
SATA
C2000 SoC SATA3 (6Gbps), SATA2 (3Gbps)
Network Controllers
C2000 SoC I354 Quad GbE controllers (MACs)
Virtual Machine Device Queues reduce I/O overhead
Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output
USB
2.0 C2000 SoC
IPMI
Support for Intelligent Platform Management Interface v.2.0
IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
Aspeed AST 2400 BMC
Video
BMC integrated Aspeed AST2400
Input / Output
Serial ATA
2x SATA3 (6Gbps) ports
4x SATA2 (3Gbps) ports
LAN
4x RJ45 Gigabit Ethernet LAN ports
1x RJ45 Dedicated IPMI LAN port
USB
7x USB 2.0 ports (4 rear, 1 Type A, 2 via header)
Serial Port
2x Fast UART 16550 Serial Port (1 rear, 1 via header)
DOM
1x SATA DOM (Disk on Module) power connector
VGA
1x VGA Port
Others
TPM 1.2 header
Form Factor
1U Rackmount
Available Colors
Black
Front Panel
Buttons
Power On/Off button
System Reset button
LEDs
Power LED
Hard drive activity LED
2x Network activity LEDs
System Overheat LED
Expansion Slots
PCI-E
1x PCI-E 2.0 x8 slot via riser
Drive Bays
HDD
2x 3.5" or 4x 2.5" internal SATA2 hard drive bays (optional)
Power Supply
200W Low Noise AC-DC power supply with PFC
AC Voltage
100 - 240V, 50-60Hz, 3-1.5 Amp Max
+5V
16.0 Amp
+5V standby
2.0 Amp
+12V
15.0 Amp
-12V
0.8 Amp
+3.3V
17.0 Amp
System BIOS
BIOS Type
128Mb SPI Flash EEPROM with AMI UEFI BIOS
BIOS Features
Plug and Play (PnP)
DMI 2.3
ACPI 5.0
USB Keyboard support
SMBIOS 2.7.1
UEFI
RoHS
RoHS Compliant
Item Dimension (L"xW"xH"):
16.8 x 14 x 1.7
Weight:
12 lb
Warranty Information:
1 Year
