*Product availability is subject to suppliers inventory
Brand | Tripp Lite |
---|---|
Model | PDUMH30HVNET |
Type | Switched |
Rack Size | 2U |
Style | Rackmount |
Front Panel LEDs | 16 power availability LEDs confirm power off / on status for each built-in outlet; Two additional LEDs identify which bank the visual current meter is reporting (Bank 1, Bank 2 or Banks 1&2 combined) |
Certifications | Tested to UL 60950-1 (USA, Canada), Class A (Emissions), NOM (Mexico), TAA Compliant |
ROHS | RoHS compliant |
Input Voltage | 208/240V |
Maximum Input Current | 30A |
Input Connector(s) | NEMA L6-30P |
Cord Length | 10 ft |
Output Voltage | 208/240V |
Output Frequency | 50/60Hz |
Output Connector(s) | 16 C13 outlets |
Overload Protection | Outlets are arranged in two banks of 8. Each bank is protected by a separate 15A thermal circuit breaker |
Operating Environment | -15 - 50 Celcius degree |
Operating Relative Humidity | 5 - 95% |
Operating Elevation | 0 - 10,000 Feet |
Features | 30 A 208 / 240V Switched Power Distribution Unit / PDU with built-in web/network interface(Agency derated to 24 A continuous) Attached L6-30P 208 / 240V single phase input, 12 Feet / 3.6 M input cord 2U horizontal rackmount form factor 16 switched c13 outlets Supports power-on, power-off or reboot of each outlet on a real-time or programmable basis Enables reboot of locked equipment, custom power-on / power-off sequences, load-shedding of optional loads and disabling unused outlets Network interface provides PDU control and data regarding input voltage and total output load level in amps Digital display continuously reports output load in amps in 3 segments (load bank 1, load bank 2, total) Supports user-specified alarm notification thresholds In-rack environmental reporting with optional ENVIROSENSE temperature / humidity sensor and rack access notification with up to 4 optional SRSWITCH door sensors DHCP / Manual configuration support 10 / 100 Mbps auto-sensing Real-time clock backup maintains the time of day and date even if the PDU is unpowered Tiered access privileges allow an administrator and a guest to login via web browser Alert notifications via email or SNMP traps offer immediate event notification Firmware upgrade ability supports future product enhancements Supports HTTP, HTTPS, PowerAlert Network Management System, SMTP, SNMPv1, SNMPv2, SNMPv3, Telnet, SSH, FTP, DHCP, BOOTP, NTP protocols Fully compatible with FREE PowerAlert Network Management System / NMS Software 2U horizontal rack installation supported in 2 or 4 post racks with included mounting brackets Mounting brackets support wall-mount and under-counter installation in many applications Included cord retention brackets Compliant with the Federal Trade Agreements Act(TAA) for GSA Schedule purchases |
Dimensions | 3.50" x 17.50" x 12.50" |
Weight | 13.80 lbs. |
Package Includes | Rackmount PDU Installable 2U mounting brackets |
