Wiistar 3G SDI to AV Converter BNC to RCA Audio Scaler Support Convert HD-SDI,3G-SDI Signal for TV

Introduction: This SDI to AV (CVBS) converter allows HD-SDI and 3G-SDI signals to be shown on normal TV while ensuring high bit rates of 2.970G bit/s to give you fast signal transmission without any loss, and thereby expensive monitor can be replaced by normal TV. It also support L/R analog audio output and can be connected to sound system to get perfect music.
Features: Operation at 2.970G bit/s, 2.970 / 1.001G bit/s, 1.485G bit/s, 1.485 / 1.001G bit/s Auto video mode detection(3G/HD) Conversion from SMPTE 425M level B to level
A 1080p 50/60 4:
2: 2 10-bit Connect with other units to extend your signal over long distances 2CH analog audio output Supports signal transmission distances up to 200M for HD signals and 100M for
3G signals Note: Cable tested with Belden 1694A. Operation distances may vary if used with another type of cable.
Specifications: SMPTE
Standard: 425M Level A&B, 424M, 292M, 259M-C
SDI Transmission Rates: 2.970G bit/s and 2.970 / 1.001G bit/s
SDI in Resolution:
HD: 720p@50/60, 1080i@50/60.
3G: 1080p@24/25/30/50/60 CVBS
Output Resolution: PAL/NTSC-M (optional)
Input port: 1xBNC(HD/3G-SDI)
Output port: 3xRCA(CVBS, L/R)
Power Supply: DC 5-12V
Dimension (mm): 95 (L) x65 (W) x28 (H)
Operating Temperature: 0?~40?/32?~104?
Storage Temperature: -20?~60?/-4?~140?
Relative Humidity: 20~90%RH(Non-condensing)
Power Consumption (Max): 2W
Package Contents: Main Unit (3G SDI to AV Converter) *1 US Standard Power Adapter*1 User Manual*1Product informationProduct Dimensions 3.74 x 2.56 x 1.1 inchesItem Weight 11.4 ouncesASINB0797T5HZ7Item model number43237-187380Customer Reviews 3.9 out of 5 stars21 ratings 3.9 out of 5 starsBest Sellers Rank#1, 092 in Video ConvertersIs Discontinued By ManufacturerNoDate First AvailableJanuary 23, 2018ManufacturerWiistarWarranty
