Model |
WD07-C10-J1800-4G128G |
Part Number |
WD07-C10-J1800-4G128G |
Form Factor |
All-in-One |
Colors |
Black |
Operating System |
Windows 7 |
CPU Type |
Celeron |
CPU Speed |
J1800 (2.41 GHz) |
GPU/VGA Type |
Intel HD Graphics |
Memory Capacity |
4 GB DDR3 |
SSD |
128 GB |
HDD |
No |
Screen Size |
15" |
Touchscreen |
Yes |
Model Number: HUNSN WD07
Opening Hole Size: 334*232mm (Length*Width)
Screen Type: 10 Points Capacitive Touch Screen
CPU: Intel® Celeron® Processor J1800 (1M Cache, up to 2.58 GHz)
RAM/SSD/HDD: Max 8G RAM, 1* MSATA + 1* 2.5 Inch HDD
I/O: 3*RS232+VGA+LAN+3*USB 2.0 +1 USB 3.0 +DC+Audio In &Out
I/O: Optional LPT, Default Without
Physical Dimension: 355.8 * 287.3 * 53.6 (mm)
Gross Weight: 6.5 KGS
Features: Resolution 1024*768, Screen Ratio 4:3
Panel Structure:
Panel Size: 15 Inch LED Screen
Resolution: 1024*768
Display Brightness: 430cd/m (2)
Contrast:
700: 1
Response Time: 8ms
Touch Type: Using high-quality resistance touch screen click life> 1 million times
Usage Environment:
Operating Temperature: -10? ~60? Surface Air Flow
Operating Humidity: 10% ~ 95% @ 40? without condensation
Storage Temperature: -20? ~ 70?
Installation Method:
1: Embedded (Recommended)
2: Wall-mounted
3: Desktop
4: Cantilevered
5: Other Installation Methods
Motherboard:
BIOS: AMI 32Mbit, Support Diskless Start, Wake-Up on Lan, Call Boot (Power On Boot), Watchdog And Other Functions
Motherboard: Fanless Design
I/O Interface:
Network: 1* Realtek 8111E 10/100/1000M
Audio: Realtek®ALC662 HD Audio
Package Information:
Package Size: 44CM (L) * 36.2CM (W) * 15.5CM (H)
Physical Weight: 4KG / 5.1KG (Net/Gross)
Power Supply:
Input: 180-240V~ 1.0A 50-60Hz
Output: 12VDC 4A MAX
Power Cord: Power Cord*1
Touch Pen: Resistance touch pen*1 (10 capacitive touch screen without touch pen)
Buckle: Embedded Installation Buckle* 1 Set
Warranty: 3 years
System Support: Windows 7/8/ 8.1 /10, WES7/8, Linux Ubuntu, Vxworks etc;
System Default Option: Windows 7 as the default option;
Linux ubuntu or other OS, Do need to leave us message on the order, thank you.
