ONV-POE33026PFM 22*10/100/1000M RJ45 Ports + 2*TP/SFP Combo Ports + 2*Gigabit SFP Ports POE Switch
CTNR1575696 CTNR1575696ESCAM Technology Co., Ltd
2025-05-09
/itm/onv-poe33026pfm-22101001000m-rj45-ports-2tpsfp-combo-ports-2gigabit-sfp-ports-poe-switch-1575696
USD
533.5
$ 533.50 $ 550.00
Item Added to Cart
customer
*Product availability is subject to suppliers inventory
SHIPPING ALL OVER UNITED STATES
100% MONEY BACK GUARANTEE
EASY 30 DAYSRETURNS & REFUNDS
24/7 CUSTOMER SUPPORT
TRUSTED AND SAFE WEBSITE
100% SECURE CHECKOUT
| Brand | ONV |
|---|---|
| Model | ONV-POE33026PFM |
| Switch Type | POE Switch |
| Package Contents | 1 |
The ONV-POE33026PFM, 10/100/1000Mbps L2+ managed POE+ switch from ONV, provides a reliable infrastructure for your business network. This switch delivers more intelligent features you need to improve the availability of your critical business applications, protects your sensitive information, and optimizes your network bandwidth to deliver information and applications more effectively. It provides the ideal combination of affordability and capabilities for entry level networking of industrial, small business or enterprise application which demands industrial, surveillance, IP Phone, IP Camera or Wireless applications, thus helps you create a more efficient, better-connected workforce.
Key Features? 22*10/100/1000M RJ45 Ports + 2*TP/SFP Combo Ports + 2*Gigabit SFP Ports? L2+ features provide better manageability, security, QoS, and performance.? Support L2+ Switching features including 802.1Q VLAN, Mirroring, Port isolation, IGMP Snooping, DHCP Snooping, LLDP, POE+ management, IP Source Guard, ARP inspection, ACLs etc.? Support spanning tree STP( 802.1D ) and RSTP( 802.1W ).? Jumbo frames support up to 9.6K kilobtyes.? Support enhanced management through WEB, CLI, TELNET, SSH, SNMP.? Support cable diagnosis? IEEE 802.3 af and 802.3 at.
Supports per port PoE configuration function? G. 8032, support <50ms industrial quick ring protection Benefits This PoE switch provides security, performance, quality of services, central managed and other network control capabilities. Optimized and customized design and affordable pricing, it best fit for SMB or entry-level enterprise solution.
It provides:?
Excellent performance and reliability: passed the rigorously testing to deliver excellent performance. As a managed switching solution, it also provides the flexibility to manage and prioritizes suitable-bandwidth traffic such as voice.?
Strong security: provides an advance security and gives you tight control to safeguard the network from unauthorized users.
Advanced security features include: ---Extensive access control lists (ACLs) to restrict sensitive portions of the network from unauthorized users or guests. ---virtual LANs (VLA
Ns) provide internet connectivity to guests? while isolating critical traffic from guest traffic. ---IP Source Guard and ARP inspection to prevent datagrams with spoofed addresses from being in the network. ---IEEE 802.1X port security to tightly limit access to specific segments of network.
Ordering Information Product Model: ONV-POE33026PFM
Product Description: 26-Port gigabit managed PoE switch with 22*10/100/1000M RJ45 Ports + 2*TP/SFP Combo Ports + 2*Gigabit SFP Ports, port 1 to 24 supports PoE, IEEE 802.3 af/atstandard, 30W per port, the total power is 400W.
Note: Default power supply pin type is end-span(1/2+, 3/6-), mid-span(4/5+, 7/8- ) is optional Technical parameter list Product Name 26-port Giga Managed PoE Switch Model ONV-POE33026PFM Connector Type 22*10/100/1000M RJ45 Ports + 2*TP/SFP Combo Ports + 2*Gigabit SFP Ports Bandwidth 256G Address Database Size 8K MTBF 100, 000 hours Forwarding Mode Store and Forward Buffer Memory 4M PoE Ports 24 PoE ports PoE Port Power 30W PoE Standard IEEE 802.3 af Power Consumption 400W Working
Environment Operating temperature: -20 to 55?;
Storage temperature: -20? to 75?;
Operating humidity: 10% to 90%, relative, non-condensing Certification FCC, CE, RoHS Transmission Distance 100 meters Product Size 440x290x 44.5 mm Warranty 1 year
Key Features? 22*10/100/1000M RJ45 Ports + 2*TP/SFP Combo Ports + 2*Gigabit SFP Ports? L2+ features provide better manageability, security, QoS, and performance.? Support L2+ Switching features including 802.1Q VLAN, Mirroring, Port isolation, IGMP Snooping, DHCP Snooping, LLDP, POE+ management, IP Source Guard, ARP inspection, ACLs etc.? Support spanning tree STP( 802.1D ) and RSTP( 802.1W ).? Jumbo frames support up to 9.6K kilobtyes.? Support enhanced management through WEB, CLI, TELNET, SSH, SNMP.? Support cable diagnosis? IEEE 802.3 af and 802.3 at.
Supports per port PoE configuration function? G. 8032, support <50ms industrial quick ring protection Benefits This PoE switch provides security, performance, quality of services, central managed and other network control capabilities. Optimized and customized design and affordable pricing, it best fit for SMB or entry-level enterprise solution.
It provides:?
Excellent performance and reliability: passed the rigorously testing to deliver excellent performance. As a managed switching solution, it also provides the flexibility to manage and prioritizes suitable-bandwidth traffic such as voice.?
Strong security: provides an advance security and gives you tight control to safeguard the network from unauthorized users.
Advanced security features include: ---Extensive access control lists (ACLs) to restrict sensitive portions of the network from unauthorized users or guests. ---virtual LANs (VLA
Ns) provide internet connectivity to guests? while isolating critical traffic from guest traffic. ---IP Source Guard and ARP inspection to prevent datagrams with spoofed addresses from being in the network. ---IEEE 802.1X port security to tightly limit access to specific segments of network.
Ordering Information Product Model: ONV-POE33026PFM
Product Description: 26-Port gigabit managed PoE switch with 22*10/100/1000M RJ45 Ports + 2*TP/SFP Combo Ports + 2*Gigabit SFP Ports, port 1 to 24 supports PoE, IEEE 802.3 af/atstandard, 30W per port, the total power is 400W.
Note: Default power supply pin type is end-span(1/2+, 3/6-), mid-span(4/5+, 7/8- ) is optional Technical parameter list Product Name 26-port Giga Managed PoE Switch Model ONV-POE33026PFM Connector Type 22*10/100/1000M RJ45 Ports + 2*TP/SFP Combo Ports + 2*Gigabit SFP Ports Bandwidth 256G Address Database Size 8K MTBF 100, 000 hours Forwarding Mode Store and Forward Buffer Memory 4M PoE Ports 24 PoE ports PoE Port Power 30W PoE Standard IEEE 802.3 af Power Consumption 400W Working
Environment Operating temperature: -20 to 55?;
Storage temperature: -20? to 75?;
Operating humidity: 10% to 90%, relative, non-condensing Certification FCC, CE, RoHS Transmission Distance 100 meters Product Size 440x290x 44.5 mm Warranty 1 year
