ViewHD Advanced HDMI UHD 18G 4x4 Matrix | 4K@60Hz / HDMI v2.0 | HDR | HDCP 2.2 | Model VHD-UHD4X4

Capacity: v 2.0 4K@60Hz andnbsp; |andnbsp;
Color: 4x4 VHD-UHD4X4 HDMI 4X4 Matrix is the latest enterprise grade, HDMI v 2.0 18G, four inputs to four outputs, any input to any output true matrix; support 6K@60Hz, HDR and HDCP 2.2. This item is the companion for the latest UHD / SUHD 4K displays. This advanced stated of the art unit supports the transmission of video (resolutions up to 2016P@60Hz
Ultra HD 4:4: 4) and supports high resolution digital audio formats such as LPCM 7.1CH, Dolby True
HD, Dolby Digital Plus and DTS-HD Master Audio,. It works with Blu-ray players, Set-Top boxes, home theater PCs, and game consoles. Any source is accessible at all times by any display by selecting it via the supplied IR remote control, RS-232, TCP/IP or the selection buttons on the front panel. This device supports all HDMI 3D formats. It has built-in audio extractor, the digital coax output supports audio formats up to DD+, DD 5.1CH / AC3 formats; the L/R analog audio output supports incoming 2CH / stereo HDMI audio formats.
Features: + HDMI 2.0, HDCP 2.2 / HDCP 1.4 compliant + Support video format up to 4k2k@60Hz with 24bit
RGB/YCbCr 4:4: 4 /
YCbCr 4:2: 2, and up to 4k2k@60Hz with 12bit
YCbCr 4:2: 0 + Support color space conversions among RGB, YCbCr
4:4: 4, YCbCr
4:2: 2, and xvYCC video formats + Support all HDMI 3D formats up to 2160P@30Hz + Support high resolution VESA mode video format up to QSXGA@60Hz + Support reception of any audio data conforming to the HDMI v 2.0 specification + Support simultaneous HDMI Coax and L/R audio outputs + Support RS-232, remote control, on-panel control and TCP/IP control +
Full size professional matrix: 440mm (W) x 200mm (D) x 45mm (H); weight 1820g
Package Includes: 1) VHD-UHD4X4 matrix 2) 12V 2.5A Universal 100V-240V Power Adapter with US plug 3) Operation Manual 4) Wideband IR Rx Cable 5) IR Remote Control 6) Mounting Ears 7) RS-232 Cable View
HD One Year Warranty
