Mini SAS HD SFF8644 to Mini SAS SFF8088 Hybrid Cable 2Meter66ft

2-meter ( 6.6 ft) 4x Mini-SAS (SFF-8088) to HD Mini-SAS (SFF-8644) Cables function as a "Hybrid Cable"; thus permitting the installer to link up legacy Mini-SAS devices with the latest generation of Mini-SAS HD (High Density) hardware. This 4x HD Mini-SAS to Mini-SAS cable features a universal keyed SFF-8644 pull to release lanyard connector on one end and a universal keyed SFF-8088 pull-to-release lanyard connector on the other, each of which are fully intermateabie with ANY manufacturer's 4x iPass+ HD (Mini-SAS HD) and 26-pin Mini-SAS receptacle ports. Due to Amphenol's technological lead on high-speed over copper, our HD Mini-SAS cable assemblies are thinner (i.

e. 30 AWG) and more flexible than competing HD Mini-SAS products -- providing convenient routing options and improved airflow while exceeding the performance parameters of a thicker grade cable (i. e. 28 AWG). 1m ( 3.3 ft) length. Also available in 2m ( 6.6 ft) and 3m (10 ft)
Features: Connector
A: SFF-8644 (4x HD Mini SAS)
Connector B: SFF-8088 (4x Mini SAS Universal key)
Data Rate: 6.0G bps per channel Impedance = 100 Ohms AWG30 Twinaxial 8-pair high-bandwidth low-skew wire Zinc Die-Cast connector housings for excellent durability & EMI resistance
Insertion Loss: No more than 6.0 dB max at 4.5 GHz Fully compliant to the latest SAS 2.1 AND SAS 3.0 interface specifications Subject to Serial Attached SCSI 6.0 Gbps test certification before shipment Components are UL listed
Wide operating temperature range:
Standard: 0C to +70C
Industrial: -40C to +85C RoHS compliant cable design meets environmental standards
Applications: DATA Center Servers, Storage racks, RAID systems Storage Systems SAS/SATA HBA interfaces Direct-attached storage (DAS) Switches
