Morningstar - SS-20L-12V - MorningStar SunSaver Charge Controller 20A 12VDC w/Low Voltage Disconnect

Morningstar’s SunSaver is the world’s leading small solar controller for both professional and consumer applications including standard features and capabilities not found in any other small PV controller. Morningstar’s SunSaver is the world’s leading small solar controller for both professional and consumer applications including standard features and capabilities not found in any other small PV controller. SunSavers Technology Provides • Exceptional Reliability • PWM Battery Charging • Consistent High Quality Features • Eight versions available (12 and 24 volts, 6, 10 and 20 amps) • 100% solid state • Series design (not shunt) • True 0 to 100% PWM duty cycle • Setpoint accuracy to 35 mV • Rated for 25% overloads • Fully encapsulated in epoxy potting • Marine rated terminals / anodized case • Temperature compensation • Sealed / Flooded battery select • No need to derate • Parallel for 40 amps or more • Green charging / red LVD indicators • Approved for use in hazardous locations - Class 1, Division 2, Groups A, B, C, D • ISO 9002 quality programs Temperature Compensation Yes Maximum Current 20 A Qty/ Uom 1 Each Charge Control Type PWM type with LVD LVD Option Yes PV Current 20 A Annunciation Indicator LED and LVD Adjustable Set Points Yes
