SparkFun Blynk Board - ESP8266

Key Features:

• Easy to use app builder; drag and drop widgets
• Add a variety of buttons, sliders, graphical displays and even RGB controllers to your phone
• Control the Blynk board or any other compatible hardware remotely by displaying sensor data, analyzing your surroundings, activating a function of your project and much more
• Comes with Blynk app subscription

The SparkFun Blynk Board is specially designed to work with the ‘widgets’ within the Blynk mobile app to create your next IoT project. Monitor local weather conditions, control LEDs from your phone, even send a tweet when it’s time to water your plants! Every Blynk Board comes fully programmed and also includes a Blynk subscription code card (15k Energy at a $10 value), which will be needed to connect the Blynk Board to your Blynk account, connect to a Wi-Fi signal and you are ready to start Blynking!

The onboard ESP8266 framework allows you to connect to most 2.4GH z WiFi networks (open or password protected). The Blynk Board input/ouput (I/O) pins can either control motors or LEDs, or read in values from light & position sensors. Each of the pins are located on the edge of the board and interface with alligator clip cables – a staple interface cable for beginner and advanced electrical engineer alike. Multi-colored LEDs indicate all sorts of status modes including how to identify which board is yours.

Item Specifics
ESP8266-Based
On-Board Si7021 Temp/Humidity sensor
Solderless pin connectors - compatible with alligator clips
On-Board FTDI for re-programming
On-board WS2812 RGB LED
General purpose LED and button
ADC scaled to 0- 3.3V
Expansion connectors for I2C and WS2812 output
LiPo battery charger
Arduino programmable
No programming required to connect the board to Blynk and run through the example projects
Blynk Subscription Code-Card Included
