Clear Epoxy, High Impact, Low Viscosity Adhesive for Fiber Optic Assembly, Small Potting & Sealing Applications, Multimode & Single Mode Connectors, 2 Part, AA-BOND F113, 5gm pouch

- PRODUCT DESCRIPTION: AA-BOND F113 is an Optically Clear, low viscosity , High impact epoxy adhesives developed for bonding and small volume potting of plastic or glass optical fibers, lenses and prisms, LED displays, and other optical components. AA-BOND F113 is recommended for laminating, bonding, and sealing applications where excellent wetting, good pot life and improved impact strength properties are required. AA-BOND F113 is two parts adhesive easily mixed and cured at room temperature and develops strong bond to glass and glass fibers, ceramics, many metals and most rigid plastics. AA-BOND F113 bonds offer resistance to mechanical impact and thermal shock, and is also resistant to weather, water, gases and vapors, petroleum products, and mild acids and alkalis. - GENERAL PROPERTIES: Appearance: Clear Components: 2 component - requires mixing Mix Ratio by weight: 100:30 / Resin:Hardener Benefits: Low viscosity Thermal shock and impact resistant Low stress connections Cure Type: Room temperature or Heat Cure Operating Temperature: -60 to 120 °C Typical Applications: Fiber optic assembly, multimode and single mode connectors, small potting and sealing applications - UNCURED PROPERTIES: Viscosity @ 25 °C: 175 Thixotropic Index: 1.0 Specific Gravity: 1.23 Pot Life: 1.5 hours - CURE SCHEDULE: 24 hours @ 25°C 1-2 hours @ 65°C - CURED PROPERTIES: Coefficient of Thermal Expansion, cm/cm/ºC: 6.20×10+01 Glass Transition Temperature (Tg), ultimate, °C: 102 Hardness, Shore D: 86 Refractive Index: 1.51 Water Absorption , after 24 hours saturation, %: 0.07 - GENERAL INFORMATION: For safe handling information on this product, consult the Material Safety Data Sheet, (MSDS). - AVAILABILITY: This epoxy can be supplied in various different packages. Call (888) 522-6742 for more information.
