Granit 1910i Technical Specifications
Mechanical
Dimensions (LxWxH) 133 mm x 75 mm x 195 mm (5.2? x 2.9? x 7.6?)
Weight 300 g (10.6 oz)
Electrical
Input Voltage 4.0 to 5.5 VDC
Operating Power 2.35 W (470mA @ 5 VDC)
Standby Power 0.5 W (100mA @ 5 VDC)
Host System Interface USB
Environmental
Operating Temperature* -30°C to 50°C (-22°F to 122°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Humidity Up to 95% relative humidity, non-condensing
Drop Designed to withstand 50 2 m (6.5') drops to concrete at -30°C
Tumble 5,000 1m (40?) tumbles
Environmental Sealing IP65
Light Levels 0 to 100,000 lux (9,290 foot-candles)
ESD ±20Kv air discharge, ±8kV contact discharge
Scan Performance
Scan Pattern Area Imager (838 x 640 pixel array)
Motion Tolerance Up to 610 cm/s (240 in/s) at 16.5 cm (6.5") and 381 cm/s (150 in/s) at 25 cm (10.0") for 13 mil UPC
Scan Angle ER Focus: Horizontal: 31.6°; Vertical: 24.4°
Symbol Contrast 20% minimum reflectance difference
Pitch, Skew 45°, 65°
