Color |
White |
Camera Type |
2 Megapixel |
Type |
Bullet Camera |
Connection Type |
BNC |
Camera
Image Sensor
2 MP CMOS image sensor
Resolution
1920 (H) × 1080 (V)
Frame Rate
PAL: 1080p@25fps NTSC: 1080p@30fps
Min. illumination
Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
Shutter Time
PAL: 1/25 s to 1/50, 000 s
NTSC: 1/30 s to 1/50, 000 s
Slow Shutter
Max. 16x
Lens
3.6 mm fixed lens
Horizontal Field of View
83.6° (3.6 mm)
Lens Mount
M16
Day & Night
Color
Synchronization
Internal synchronization
WDR (Wide Dynamic Range)
120 dB
Menu
AGC
Yes
White Balance
Auto/Manual
BLC (Backlight Compensation)
Yes
Privacy Mask
4 programmable privacy masks
Motion Detection
4 programmable areas
WDR
Yes
Functions
Brightness, Sharpness, 3D DNR, Mirror, Smart light
Interface
Video Output
1 HD analog output
Switch Button
TVI/AHD/CVI/CVBS
General
Operating Conditions
-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
Power Supply
12 VDC ±25%
Power Consumption
Max. 4.2 W
Protection Level
IP67
Material
Front Cover: Metal, Main Body: Plastic, Bracket: Metal
White Light
Up to 131ft(40 m)
Communication
Up the coax, TVI output
Dimensions
223.1 mm × 77.1 mm × 82.6 mm (8.78" × 3.04" × 3.25")
Weight
Approx. 436 g (0.96 lb.)
