Shinybow - SB-1116G - 1x16 VGA(RGBHV) Splitter

An ultrahigh speed current feed back amplifier with an excellent 5500V/as slew rate that results in a rise time of 545ps, making it ideal as a pulse amplifier. The high slew rate lowers the effect of slew rate limiting and results in the large signal Bandwidth 440MHz(G=+2), Small signal Bandwidth (-3dB) 1000MHz(G=+1) delivers computer resolutions up to 2048 x 2048 at distances up to 1 50 feet away without signal deterioration. Signal quality is maintained over a wide bandwidth wyth worst-case distortion of-40dBc@250MHz (G=+10, 1 Vp-p). Input and output connectors are HD-15 female type. The SB-1116MRM is housed 19 inch rack mountable metal cases, 1 RU high. All units are +12VDC powered, which includes a power adaptor. Features: 1 input to 16 outputs VGA Distribution Amplifier Large Signal Bandwidth 440MHz, G=+2 Small signal Bandwidth(-3dB) 1GHz, G=+1 Settling Time 10 ns to 0.1%, 2 V Step, G=+2 Low Distortion over Wide Bandwidth High resolution for VGA, SVGA, XGA, UXGA, WUXGA 1920x1200 High Output Drive 175 mA Output Load Drive Scan rates accepted : 50Hz or 60Hz Enclosure type : Support wall mountable Support Lower power consumed full load under 500mA Rack Mount bracket optional Specifications: Type of Amplifier: 1 input To 16 outputs VGA Distribution Amplifier I/O signals: RGBHV, RGBS, RGsB (RGB Level Range 0.5~2.0 Vp-p) Video Bandwidth: Large signal 440MHz, small signal(-3dB) 1 GHz Slew Rate: 5500 V/aS, 4V Step, G=+2 Settling Time: 10 ns to 0.1%, 2 V Step, G=+2 Gain flatness: 0.1 dB to 75MHz, Rl=150% 1. 0.01% differential gain error; Rl=150% 2. 0.01% differential phase error; Rl=150% Low distortion SFDR: -66 dBc @ 20 Mhz, Second Harmonic 1. -75 dBc @ 20MHz, Third Harmonic High Resolution: Maximum 2048 x 2048 Amplifier Unit: FCC, CE, RoHS(2002/95/EC) Power Supplies: UL, CE, CSA, TUV, BS Power distortion: 400 mA full load Dimensions (W.D.H.): 17.32 (W)x 7.80 (D)x 1.73 (H) Power Voltage Input: DC 12V@500mA, -3Aaccepted In the box: SB-1116 VGA DA Users Guide AC/DC Adapter: 12VDC, 500mA Rack mount Kit
