Adafruit FONA 808 - Mini cellular gSM + gPS Breakout ADA2542]

cellular + gPS tracking, all in one Introducing Adafruit FONA 808 MinigSM + gPS, an all-in-one cellular phone module with that lets you add location-tracking, voice, text, SMS and data to your project in an tiny package. This module measures only 1.75 x 1.6 but packs a surprising amount of technology into its little frame. At the heart is a powerfull gSM cellular module (we use the latest SIM808) with integrated gPS. This module can do just about everything. Onboard LiPoly battery charging circuitry so you can take your project on the go. Use any 500mAh+ LiPoly or LiIon battery and recharge over the MicroUSB when necessary.

Two LEDs let you know when its charging and done Standard 4-pole TRRS headphone jack. Use any Android or iPhone-compatible headset with mic Breakouts for external 32O speaker and electret mic if you dont want to use a headphone Level shifting circuitry so you can run it with 2.8V to 5V logic. Vibrational motor (buzzer) driver so you can have noiseless notifications uFL connections for external antennas Indicator LEDs for power and network connectivity Standard SIM slides into the back On its own, this module cant do anything. It requires a microcontroller to drive it! We suggest and use an Arduino but any 3-5V microcontroller with a UART can send and receive commands over the RX/TX pins.
UPC NO: 600346598942
SKU: CONSEB011YGWAGK
