*Product availability is subject to suppliers inventory
Brand | Comtrol Corporation |
---|---|
Model | 99456-5 |
Type | Device Server |
Specifications | Temperature: -34.6°F (-37°C) to 165.2°F (74°C) Ambient Operating -40°F (-40°C) to 185°F (85°C) Storage Humidity: 20 to 80% Non-condensing Operating 8 to 80% Non-condensing Non-operating Altitude: 0 ftto 10000 ft Additional Information: NS-Link COM/TTY Port Re director Supports native COM, TTY, or TCP/IP Socket communication modes Software selectable RS-232, RS-422, or RS-485 serial interfaces Compatibility: Microsoft Windows NT Microsoft Windows 2000 Microsoft Windows Server 2003 Microsoft Windows XP Linux Certifications & Standards: CE Mark FCC Part 15 Subpart B Class A C-Tick CUL RoHS 2002/95/EC RFC 1006 IEEE 802.3 IEEE 802.3u Immunity: EN55024 EN61000-4-2 EN61000-4-3 EN61000-4-4 EN61000-4-5 EN61000-4-6 EN61000-4-8 EN61000-4-11 IEC 1000-4-2 IEC 1000-4-3 IEC 1000-4-4 IEC 1000-4-5 IEC 1000-4-6 IEC 1000-4-8 IEC 1000-4-11 Emission: EN55022 & A1:2000 IEC 1000-3-2 IEC 1000-3-3 CISPR-22 ICES-003 Safety: EN60950 IEC 60950 CSA C22.2 No. 50/UL60950 Color: Black Form Factor: 1U Rack-mountable Dimensions: 1.74" x 17.25" x 10.80" Weight (Approximate): 6.40 lbs. |
Features | Data/Stop Bit: 8 Data Bit8 2 Stop Bit2 Flow Control: Hardware Flow Control Software Flow Control Interfaces/Ports: 32 x RJ-45 1 x RJ-45 LAN Data Transfer Rate: 10 Mbps Ethernet 100 Mbps Fast Ethernet 50 Kbps to 230 Kbps Serial Management: PortVision Remote Management Web-based configuration Telnet and ping SNMP Protocols: TCP/IP BootP DHCP ARP RARP HTTP Security Features: Real-time e-mail event notification Processor: 1 x ARM7 44 MHz Standard Memory: 8 MB RAM 4 MB Flash Memory Status Indicators: Status Ethernet Link/Activity Collision 100MB Ethernet RX/TX Per Port Input Voltage: 90 V AC to 260 V AC Frequency: 60 Hz Power Consumption: 22 W |
