Diamond Antenna V2000A Base antenna, 6m/2m/70cm, UHF, 8ft

Diamond Antennas V2000A Tri-band Base Antenna

The V2000A is the U. S. version of the V2000 Tri-Band Antenna. This antenna has been optimized for the U. S. FM Bands. The V2000A utilizes a linear phase shift design to couple the different frequency band sections together. A watertight joint assembly connects the two antenna sections into one rigid assembly. The resulting antenna has the same strength as a one piece structure.

This is the ideal antenna for FM operation on 6 meter, 2 meter, and 70cm bands.

Similar in construction to the X200A dualband, the V2000A has an additional counterpoise radial – adjustable for 6m (52-54 MHz only). With 6m activity, enjoy the freedom of 3 bands in one compact antenna.

• Fiberglass radomes
• Overlapping outer shells for added strength
• Strong waterproof joint couplings
• Stainless steel hardware
• Wide band performance
• Highest gain
• High wind rating
• DC ground; antenna element and radials connected to mounting pipe
• Three radials
• One Year Limited Warranty against defects in material or workmanship

• Bands: 6m/2m/70cm
• Frequency (MHz): 52-54/144-148/440-450
• Gain: 2.15 dBi/ 6.2 dB/ 8.4 dB
• Impedance (nominal): 50W
• VSWR:
  1.5: 1 (typical)
• Power Rating: 150 watts
• Element Phasing: 1/2l/2-5/8l/4-5/8l
• Max Wind Rating: 112 m. p. h.
• Mast Dia.
  Acceptance: 1.2 to 2.4 inches
• Length/Weighta: 8.3 ft. / 2.6 lbs.
• Connector: SO-239 Female
