Type |
Attendance Machine |
Color |
Black; Silver |
Sizes/Dimensions |
N/A |
SPECIFICATION:
CPU: Cortex-A7, Neon FPU, NPU @ 1.2TOPs
Size: 425mm*203mm*203mm
Power:<20W
Storage: 4Gb DDR3, 8GB EMMC
System: Linux 3.10
BT: support V4.2
Speaker: support
Microphone: none
LCD: 7inch Display, 800*1280, MIPI port
OTG: support
RTC: support
Fill Light: LED white 12VDC, 2~4W
Infrared Light: LED Red 1.5V,200mA
Binocular camera:MIPI+LPT, 200W pixel
Supported:COM ,RFID, uboot, RESET, R S232, Relay
Not supported: T P, SD card
Power: DC12V input (suit 9~16V wide voltage)
Infrared Thermometer :Body temperature measure, Normal Pass, Fever Alarm.
Measure distance:<1m
Measurement Range:(25.0°C ~45.0°C )
Measure Accuracy:±0.5°C
Thermal image filed of view: 32 x 32°C
Face Recognition: Identify People in Masks
Packing list:1x attendance Machine, 1xfloor stand,1x stand base
