toa p924mk2 modular single channel power amplifier, 240w output power, master volume control, direct lowimpedance output mode bypasses output transformer, proven toa quality and reliability

TOA P-924MK2 Modular Single Channel Power Amplifier, 240W Output Power, Master Volume Control, Direct Low-Impedance Output Mode Bypasses Output Transformer, Proven TOA Quality and Reliability Key Features Proven TOA Quality and Reliability Input Module Slot accepts most TOA plug-in modules for custom system configurations Direct Low-Impedance Output Mode bypasses output transformer Direct Input for connecting an external mixer or other source Master Volume Control Low Cut Switch to limit low frequency response Rear Panel AC Convenience Outlet for powering external equipment Turn-On Delay disconnects output during power-up Volume Control Security Knob Included Optional Rack-Mount Kits UL/cUL Listed Specifications Output Power: 240W RMS Power Bandwidth: (D) 20 - 20kHz, 0.5% THD; (T) 50 - 20kHz, 0.5% THD Frequency Response: (D) 20 - 20kHz, 1 dB; (T) 20 - 15kHz, 1 dB; (T) 20 - 20kHz, +1 dB / -3dB Total Harmonic Distortion: 0.01% at 1k Hz, rated output Inputs: 1 modular input port/1 direct input Input Sensitivity & Impedance: Input port: 100mV or 1000mV (switchable)/10k; Direct input: 100mV or 1000mV (switchable)/10k Outputs: Main (T): 8, 25V & 70V, balanced; Main (D): 4, unbalanced Output Regulation (D): Less than 0.5dB, no load to full load; (T): Less than 1.0dB, no load to full load Dynamic Range: Input level switch in 0 dBV (1000mV) position: 108dB, Input level switch in -20dBV (100 mV) position: 90 dB Indicators: Normal, Peak, Power, Protect, and Signal LEDs Protection: Self-protection, with 2 AC fuses (1 internal) and 2 DC fuses Power Consumption: 120V/3A Temperature Range: 12F to 140F Dimensions: 16.5"x6.0"x13.2" Weight: 43.0 lbs
UPC NO:844632065286
SKU:ADIB004HNDT5Y
