hifiberry digi+ standard

The HiFiBerry Digi+ is a high-quality S/PDIF output board for the Raspberry Pi model A+/B+ and the new Raspberry Pi 2. It is designed as an add-on board that connects to the P1 and P5 header of the Raspberry Pi. Dedicated S/PDIF interface chip supports up to 192kHz/24bit resolution Optical (Toslink) and electrical outputs Bit-perfect output, audio data stream will not be modified in any way Connects directly to the Raspberry Pi, no additional cables needed No soldering. The Digi+ comes as a pre-fabricated kit. You just plug it onto the Raspberry Pi B+.

The board conform to the Raspberry Pi hardware-attached-on-top (HAT) specification. That means it perfectly fits your Raspberry Pi B+. Directly powered from the Raspberry Pi, no additional power supply
Optional: high-bandwidth output transformer provides full galvanic isolation of the electrical output (not in the standard version) Integrated EEPROM for automatic configuration (with write-protection). Note that this feature is still in development by the Raspberry Pi foundation. You will be able to upgrade your HiFiBerry DAC+ when it is officially available. The sound card already works without this feature. Comes with all components required to mount it. We include 4 M 2.5 x12mm spacers to fix the board onto the Raspberry Pi. Note about the compatibility with Raspberry Pi Model A and
B: This board is only compatible with the Raspberry Pi model A+, B+ and 2B.
Important note: While the hardware is able to output DTS/Dolby Digital, software has to be adapted to support this. We will support the developers to implement this. Unfortunately we can't guarantee that this feature will work with a specific software. Please ask the developers of the software if this is supported. Note that this model is not compatible with older Raspberry Pi model A and B units!
UPC NO: 731236507284
SKU: ADIB0147RPBXC
