LTS CMIP9743NW-SZ HD IP 4MP 2.8-12mm VF Motorized WDR Micro SD Slot Bullet Camera

Camera Image Sensor 1/3" Progressive Scan CMOS Min.
Illumination Color: 0.01 Lux @ (F 1.2, AGC ON), 0.018 Lux @ (F 1.6, AGC ON), 0 Lux with IR Shutter Speed 1/3 s to 1/100, 000 s Slow Shutter Yes Auto-Iris No Day & Night IR Cut Filter Digital Noise Reduction 3D DNR WDR 120dB 3-Axis
Adjustment Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° Lens Focal Length 2.8 to 12 mm Lens Type Motorized Aperture F 1.6 Focus Auto FOV horizontal
FOV: 104° to 29° vertical
FOV: 55° to 17° diagonal
FOV: 125° to 34° Lens Mount F14 IR IR Range Up to 164ft (50 m) Wavelength 850nm Compression Standard Video Compression
Main stream: H. 265/H.
264 Sub-stream: H. 265/H.
264/MJPEG Third stream: H. 265/H. 264 H. 264 Type Main Profile/High Profile H. 264+ Main stream supports H. 265 Type Main Profile H. 265+ Main stream supports Video Bit Rate 32 Kbps to 16 Mbps Smart Feature-set Behavior Analysis Line crossing detection, intrusion detection Face Detection Yes Region of Interest Support 1 fixed region for main stream and sub-stream Image Max. Resolution 2688 × 1520
Main Stream 50Hz: 25fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920
× 1080) 60Hz: 30fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080)
Sub-Stream 50Hz: 25fps (640 × 480, 640 × 360, 320
× 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Third Stream 50Hz: 25fps (1280 × 720, 640 × 360, 352
× 288) 60Hz: 30fps (1280 × 720, 640 × 360, 352 × 240) Image Enhancement BLC/3D DNR/HLC Image Settings Rotate mode, saturation, brightness, contrast, sharpness and white balance adjustable by client software or web browser Day/Night Switch Day/Night/Auto/Schedule/Triggered by Alarm In Network Network Storage Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS, SMB/CIFS), ANR Alarm Trigger Motion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD full, HDD error Protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour General Function One-key reset, anti-flicker, three streams, heartbeat, password protection, privacy mask, watermark, IP address filter API ONVIF (PROFILE S, PROFILE G), ISAPI Simultaneous Live View Up to 6 channels User/Host Up to 32 users 3 levels: Administrator, Operator and User Web Browser Plug-in required live view: IE8+, Chrome 41.0 -44, Firefox 30.0 -51, Safari 8.0 -11
Plug-in free live view: Chrome 45.0 +, Firefox 52.0 + Interface Audio 1 input (line in), 1 output (line out), mono sound, terminal block Alarm 1 input, 1 output (max. 12 VDC, 30 mA), terminal block Communication Interface 1 RJ45 10M/100M self-adaptive Ethernet port Video Output 1Vp-p composite output (75 O) (For adjustment only) On-board storage Built-in Micro SD/SDHC/SDXC slot, up to 128 GB SVC H. 264 and H. 265 encoding support Reset Button Yes Audio Environment Noise Filtering Yes Audio Sampling Rate 8kHz/16kHz/32kHz/ 44.1 kHZ/48kHz Audio Compression G. 711/G. 722.1 /G. 726/MP2L2/PCM Audio Bit Rate 64Kbps(G. 711)/16Kbps(G. 722.1 )/16Kbps(G. 726)/32-192Kbps (MP2L2) General Operating Conditions -30 °C to +60 °C (-22 °F to +140 °F), humidity 95% or less (non-condensing) Power Supply 12 VDC ± 25%, PoE ( 802.3 at, Power Consumption and Current 12 VDC, 1.2A, max. 14.5W PoE ( 802.3 at, 42.5V to 57V), 0.5A to 0.3A, max. 18W Protection Level IP67 Material Metal Dimensions F 105.1 × 297.5 mm (F 4.1" × 11.7" )
Weight Camera: Approx. 1285 g ( 2.8 lb.
) With Package: Approx. 1964 g ( 4.3 lb. )
