NTI E-DI16DO16-D Digital Input/Output Expander (Open-Collector Outputs) DIN Mount

The E-DI16DO16-D Digital I/O Expander with Open-Collector Outputs adds 16 digital inputs and 16 digital open-collector outputs to an E-2D/5D/16D. Door switches, emergency / panic buttons and vibration sensors are some of the many digital input sensors that the expander supports. The 16 open-collector outputs can sink up to 500mA of current to control externally powered devices running on up to 24V DC, such as the Automatic Voice Dialer (runs on 9-18VDC), which is controlled by the ENVIROMUX system. For example, if a temperature sensor that is connected to the ENVIROMUX system detects that temperature has risen to critical levels, the ENVIROMUX system can activate the voice dialer connected to the expander to notify personnel of the issue.

Features

• Adds 16 digital inputs and 16 digital open-collector outputs to the E-2D/5D/16D
  • Interfaces with the E-2D/5D/16D via the RJ45 Sensor Port
• Digital inputs:
  • 16 screw terminal pairs for connecting dry contact devices
    • One screw terminal pair for tachometer; 0 to 255 Hz
  • Accepts 26 to 16AWG wire
  • Potential free
  • Voltage range: 0 to +36VDC
  • Over-voltage surge protected
• Digital outputs:
  • 16 screw terminal pairs for open-collector outputs
  • Accepts 26 to 16AWG wire
  • Rated sink current: 500 mA per output
  • +5VDC, 22kΩ pull-ups
  • Voltage range: 0 to +24VDC
  • Over-voltage surge protected
• Supports CAT5/5e/6 cable up to 500 ft. (152.4 m)
• Control via SNMP:
  • Requires read-write community configuration.
  • Digital inputs are fixed values (not writable) while open-collector outputs are writable.
• Powered by E-2D/5D/16D.
• Optional DIN mounting available.
• Dimensions WxDxH: 6.49x3.10x1.08 in (165x79x27 mm)
